DIG-DOG Wheeled Skid Steer Loaders 0.3-1.2 tons

Item No.: WSL
  • KEY SPECS::
    Wheeled skid steer
    Track skid steer
    Related Load: 0.3-1.5 ton
    Upgradeable Configuration
    Custom Attachments
Description Specification Details FAQ Review
Description

DIG-DOG Skid Steer Loaders For Sale

DIG-DOG skid steer loaders with strong power and rich attachments, can better adapt to the operations in narrow space and is an ideal tool for road construction, municipal maintenance, port handling, garden maintenance, and pasture production, featuring low operation cost and remarkable economic benefits.

Advantages and Highlights:

1. Strong and Efficient Power Transmission System

-The renowned brand engine equipped features strong power, ultra-low emission, and higher fuel efficiency.
-The static hydraulic drive technology adopted features stable drive and high efficiency and reliability.
-The fully-sealed sprocket case and high strength chains feature automatic lubrication and maintenance-free.

2. Incomparable Multi-Functionalities

The international interchangeable quick-change coupling enables the change of tens of attachments, including sweeper, planer, breaking hammer, and ditcher, rapidly and conveniently.

3. Solid and Reliable Design

The integral frame adopted features compact structure and high firmness and reliability. All critical structural parts are optimized through finite element analysis to realize reasonable stress distribution.

4. Flexible Operations

The bucket can automatically maintain level status during lifting to prevent scattering of material and improve working efficiency.
Skid Steer Loaders For Sale | Chinese Skid Steer Manufacturer

Customer Photos

Skid Steer Loaders For Sale | Chinese Skid Steer Manufacturer

Attachments

1、Material loading and unloading attachments (fork shovel, standard bucket, combination shovel, sieve shovel)
2、Municipal attachments (angled sweepers, closed sweepers, crushing hammers, vibratory compactors, milling machines, trenchers, snow pushers, snow throwers, ice breakers, vibratory ice breakers)
3、Construction attachments (excavators, mixers, disk trenchers, digging arms, bulldozers)
4、Logistics attachments (holding forks, tandem bars, soft pack clamps, crane hooks, side shifting forklifts)
5、Gardening and agricultural attachments (grass forks, tree removers, graders, lawn mowers, rototillers, augers)
Skid Steer Loaders For Sale | Chinese Skid Steer Manufacturer
Skid Steer Loaders For Sale | Chinese Skid Steer Manufacturer
Skid Steer Loaders For Sale | Chinese Skid Steer Manufacturer

Packaging&Shipping

Skid Steer Loaders For Sale | Chinese Skid Steer Manufacturer
Skid Steer Loaders For Sale | Chinese Skid Steer Manufacturer
Specification

DIG-DOG Skid Steer Loaders For Sale

Model WSL30 WSL40 WSL45 WSL60 WSL65 WSL100 WSL120
Operating load  (kg) 300 500 700 850 1050 1100 1200
 Max Speed(km/h) 9 10 12 12 12 12\18 12\18
Rated flux  (L/min) 37 60 62.5 75 75 75 75
High Flow Flux (L/min) * * * * 120 140 140
Tire(track)  model 23*8.5-15 8.5-15 10-16.5 12-16.5 12-16.5 12-16.5 12-16.5
Rated power (Kw) 18.4 37 37 45 55 74 103
Fuel tank capacity (L) 25 60 70 80 75 90 90
self weight bucket  (kg) 1500 2300 2700 2800 3500 3550 3600
Bucket capacity  (m³) 0.2 0.3 0.4 0.4 0.5 0.55 0.55
Overall operating height (mm) 3126 3300 3980 4000 4070 4070 4070
Height to bucket hinge pin (mm) 2399 2725 3080 3100 3150 3150 3150
Hheight to top of cab (mm) 1813 2000 2140 2160 2160 2160 2160
Height to bottom of level bucket(mm) 2399 2558 2913 2933 2983 2983 2983
Without bucket length(mm) 1918 2300 2640 2750 2880 2880 2880
Overall length with bucket(mm) 2560 2950 3420 3490 3580 3580 3580
Dumping angle at maximum height(° ) 36 40 40 40 40 40 40
Dumping height(mm) 1882 2050 2380 2400 2450 2450 2450
Dumping reach(mm) 458 790 700 750 700 700 700
Rollback o bucket on ground(° ) 24 30 30 30 30 30 30
Rollback of bucket at full height(° ) 97 104 104 104 104 104 104
Wheelbase(mm) 722 897 991 991 1115 1185 1185
Ground clearance(mm) 148 140 185 205 205 205 205
Angle of departure(° ) 28 20 20 20 20 20 20
Front turning radius without bucket(mm) 971 1098 1168 1198 1250 1278 1278
Front tuning radius(mm) 1557 1760 1958 1958 2112 2144 2144
Rear tuning radius(mm) 1146 1296 1630 1728 1774 1857 1857
Rear axle to bumper (mm) 738 964 1108 1208 1082 1082 1082
Tread width (mm) 747 1080 1450 1500 1500 1500 1500
Width (mm) 900 1350 1720 1880 1880 1880 1880
Bucket width (mm) 914 1400 1740 1880 1880 1880 1880
Details

Details

Compact Structure:

The compact structure design allows the machine to be easily operated in a small space, which greatly increases its practicality in various working environments.

Motor Movement:

The way the motor moves is carefully designed to allow it to operate efficiently in a limited space. This not only improves work efficiency but also reduces potential risks caused by insufficient operating space.

Narrow Space Operation:

Due to the way its electric motor moves and its compact design, this machine is particularly suitable for use in narrow work spaces. Whether digging, trenching or truck loading, it delivers superior performance in limited spaces.

Engine Room Lever Control System:

The control part of the fuselage is cleverly enclosed in the engine room. This design not only enhances the overall beauty of the machine, but also ensures safety and convenience of operation. Through simple lever operation, the operator can easily control various functions of the machine.

Double Throttle Control:

Double Throttle Control is an advanced technical feature that allows the operator to finely adjust the machine's operating speed as needed. This control method improves operational flexibility and accuracy and helps achieve optimal performance in different operating environments.

Automatic Leveling System:

The automatic leveling system ensures that the machine remains stable during operation. Whether digging, loading or other operations, the system automatically adjusts the machine's angle to ensure smooth and accurate operation. This not only improves work efficiency, but also greatly reduces possible errors and safety risks due to unstable operation.

Hydraulic Braking:

The hydraulic braking system provides a powerful and stable braking effect, ensuring that the machine can stop quickly and safely under various working conditions. This braking method is more reliable than traditional mechanical braking and can provide better braking effects in complex working environments.
Skid Steer Loaders For Sale | Chinese Skid Steer Manufacturer

FAQ
1. Are You Original Manufacture?
Yes, DIG-DOG is A Manufacturer In Construction Machinery In China And We Have The Wholeseries Products You Need.
2.Which Incoterms Terms Can We Work?
Normally We Work On FOB, CFR, CIF.
3.Which Payment Terms Do You Accept?
Normally We Can Work On T/T Term Or L/C Term.
4.What About The Warranty Time?
12 Months After Shipment Or 2000 Working Hours.
5.What About The Delivery Time?
7-30 Days After Receiving The Deposit.
6.What About The Minimum Order Quantity Of The Skid Steer Loader?
The MOQ is 1 Pcs.
7.How Do I Choose The Right Skid Steer ?
-Think About Your Job Surface.
-Assess The load.
-Look At The Controls.
-Assess Other Functional Features.
-Think About Attachments For Your skid steer.
Packaging&Shipping  Skid Steer Loaders For Sale | Chinese Skid Steer Manufacturer
